Socket double KSE/AR-2V-9010, adapter frame, Installation column, white

Manufacturer GGK
Item number 4691
List price excl. VAT 37,20 EUR / piece
Product group 20-Wall installation
Packing unit 1 piece
EAN code 4018475338210
Tariff number 85366990
Product status
Core range

Pre-assembled 2-fold socket unit, consisting of mounting support, cover frame with labelling field 8x40mm and a 2-fold M45 socket 45° angled, line connection via plug-in terminals, 2-pole, 16 A/250 V~, with connection terminals according to VDE 0620, suitable for 2 angled or surface plugs, with increased contact protection according to VDE 0620, for installation in wall trunking and service poles with a 76.5 mm wide fixing track, for vertical device installation.

Model SCHUKO
Number of units 3
Connection type push-in clamp
With enhanced contact protection yes
Label space/information surface yes
Colour aluminium
RAL-number (similar) 9010
Mounting method wall trunking
Type of fastening Snap mounting
Material plastic
Halogen free no
Surface finishing matt
Nominal current 16 A
Nominal voltage 250 V
Width of device 160 mm
Height of device 85 mm
Depth of device 30 mm
