Socket double KSE/50-2-9006, with frame, DIN-rail, alu
| Manufacturer | GGK |
| Item number | 21284 |
| List price excl. VAT | 56,50 EUR / piece |
| Product group | 40-Installation devices |
| Packing unit | 4 pieces |
| EAN code | 4018475281516 |
| Tariff number | 85366990 |
| Product status |
Core range
|
Double socket outlet including mounting box, cable connection via plug-in terminals, 2-pole, 16 A/250 V~, with connection terminals according to VDE 0620, suitable for 2 angle or surface plugs, with increased contact protection, with labelling field 7x64mm, for installation in trunking with a DIN rail and a height of 60 mm.
| Model | SCHUKO |
| Number of units | 2 |
| Connection type | push-in clamp |
| With enhanced contact protection | no |
| Label space/information surface | yes |
| Colour | aluminium |
| RAL-number (similar) | 9006 |
| Mounting method | wall trunking |
| Type of fastening | mounting with screw |
| Material | plastic |
| Halogen free | no |
| Surface finishing | glossy |
| Nominal current | 16 A |
| Nominal voltage | 250 V |
| Width of device | 152 mm |
| Height of device | 81 mm |
| Depth of device | 50 mm |
