Junction box for wall duct single GDX/P-1 front-locking for BR/BRA/BRS

Manufacturer GGK
Item number 3677
List price excl. VAT 7,91 EUR / piece
Product group 20-Wall installation
Packing unit 40 pieces
EAN code 4018475228412
Tariff number 39269097
Product status
Core range

Halogen-free flush-mounting box for accommodating a commercially available device unit from the standard switch range, with strain-relief feed openings for cable diameters of 7-11mm and 11-13mm, for installation in wall trunking with a 76.5 mm wide fixing track.

Model open
Number of units 1
Type of device with bearer ring/bearer bracket
Material plastic
Mounting method installation unit screw
Strain relief possibility yes
With connection space yes
Mounting method box Front
Mounting track other
