Installation trunking LFS 40x60-9010, steel, without base perforation, pure white
| Manufacturer | GGK |
| Item number | 2301 |
| List price excl. VAT | 61,61 EUR / meter |
| Product group | 10-Cable routing |
| Packing unit | 12 meters |
| EAN code | 4018475023017 |
| Tariff number | 73089059 |
| Product status |
Core range
|
installation trunking made of sheet steel according to DIN EN 50085-2-1 for cable routing on walls and ceilings, consisting of completely overlapping cover and base. (Lower sections available with floor perforation and permanently welded partition wall on request) Freely movable cable clips must be ordered separately. Note: Potential equalisation, earthing, sound and fire protection measures must be carried out professionally.
| Height | 40 mm |
| Width | 60 mm |
| Length | 2000 mm |
| Useful cross section | 2301 mm² |
| Material | Steel |
| Material quality | other |
| Halogen free | yes |
| Anti-bacterial treatment | no |
| Surface protection | continuously galvanised and coated |
| Suitable for circuit integrity | no |
| Colour | white |
| Transparent | no |
| RAL-number | 9010 |
| Number of permanent partitions | 0 |
| Number of plug-in partitions | 0 |
| Type of fastening | other |
| Cover model | loose |
| With cable fixing clip | no |
| With protective foil | no |
| With duct connector | no |
| Delivery on roll | no |
| Pre-stamping | no |
| Degree of protection (IP) | IP30 |
| Impact strength | IK10 |
| Operating temperature | from -5 to 60 °C |
