Installation trunking LFG 40x110-7030, PVC, with base perforation, grey
| Manufacturer | GGK |
| Item number | 1460 |
| List price excl. VAT | 23,47 EUR / meter |
| Product group | 10-Cable routing |
| Packing unit | 12 meters |
| EAN code | 4018475014602 |
| Tariff number | 39259020 |
| Product status |
Core range
|
installation trunking made of PVC according to DIN EN 50085-2-1 for cable routing on walls and ceilings, consisting of a completely overlapping cover and base with double-row base perforation for fastening and a DIN rail for the installation of device installation boxes as well as partition walls, 4 cable retaining clips are included per 2 metre. Note: Sound and fire protection measures must be carried out professionally.
| Height | 40 mm |
| Width | 110 mm |
| Length | 2000 mm |
| Useful cross section | 3710 mm² |
| Material | plastic |
| Material quality | Polyvinyl chloride (PVC) |
| Halogen free | no |
| Colour | grey |
| RAL-number | 7030 |
| Number of permanent partitions | 0 |
| Number of plug-in partitions | 2 |
| Type of fastening | base perforation |
| Cover model | loose |
| With cable fixing clip | yes |
| With protective foil | no |
