Divider made of PVC TS 60 extra, for trunking FB/BR/BRA height 60mm, DIN-rail, length: 1.000 mm
| Manufacturer | GGK |
| Item number | ws10276 |
| List price excl. VAT | 5,92 EUR / piece |
| Product group | 50-Installation accessories |
| Packing unit | 30 pieces |
| EAN code | 4018475349643 |
| Tariff number | 39259020 |
| Product status |
Core range
|
Partition for mounting in installation trunking and wall trunking with a height of 60 mm and a DIN rail, for the installation and separation of cables with different voltage levels.
| Model | 1-fold |
| Suitable for duct depth | 60 mm |
| Type of fastening | snap on |
| Length | 1000 mm |
| Material | plastic |
| Material quality | Polyvinyl chloride (PVC) |
| Halogen free | no |
| Anti-bacterial treatment | no |
| Operating temperature | from -5 to 60 °C |
| Impact strength | IK07 |
| Surface protection | untreated |
| Colour | other |
